MWR Series™ – Triple Output – 14 to 50 Volt Input – 35 Watts
DC-DC Converters
The MWR Series™ is available with Class H SMD numbers. The MWR offers up to 35 watts in a 1 cubic inch case with up to 85% efficiency. It accepts a wide input range of 14-50 volts and up to 80 volts transient for up to one second.
Input voltage range 14 to 50 VDC
Transient protection 80 V for 1 second
- -55°C to +125°C operation
- Magnetic feedback
- Synchronization
- Inhibit function
- Output short circuit protection
- Up to 33 W/in3, 85% efficiency
- Undervoltage lockout
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs |
|---|---|---|---|
| Model: MWR283R312T | Nominal Input Voltage: 28 | Input Voltage Range: 14 to 50 | Number of Outputs: 3 |
| Model: MWR283R315T | Nominal Input Voltage: 28 | Input Voltage Range: 14 to 50 | Number of Outputs: 3 |
| Model: MWR28512T | Nominal Input Voltage: 28 | Input Voltage Range: 14 to 50 | Number of Outputs: 3 |
| Model: MWR28515T | Nominal Input Voltage: 28 | Input Voltage Range: 14 to 50 | Number of Outputs: 3 |
