Product Type: DC-DC Converters
Application: High Reliability

The MHV Series is available with Class H SMD numbers, 16 to 50 Vin, single, dual or triple outputs in nine different configurations and up to 15 watts output power. The converters are available with standard screening, “ES” screening, or “883” MIL-PRF-38534 Class H screening. Standard microcircuit drawings (SMD) are available.

No cross regulation on dual outputs.

  • Operating temperature -55° to +125°C
  • Compliant to Class H, see datasheet for SMD numbers
  • Input voltage range 16 to 50 VDC
  • Transient protection 80 V for 120 ms
    • 12 Vout single and dual to 75 V, 15 Vout single and dual to 60V
  • Fully isolated
  • Fixed high frequency switching
  • Output trim on single output models
  • Inhibit and sync functions
  • High power density, up to 83% efficiency
  • Case size:
    • Single and dual output models 2.125 × 1.125 × 0.400 inches (53.98 × 28.58 × 10.16 mm)
    • Triple output models 1.950 × 1.350 × 0.405 inches (49.53 × 34.29 × 10.29 mm)
    • Flanged Single and dual output 2.910 × 1.125 × 0.400 inches (73.91 × 28.58 × 10.16 mm)
    • Flanged Triple output 2.720 × 1.350 × 0.405 inches (69.09 × 34.29 × 10.29 mm)
Model Nominal Input Voltage Input Voltage Range Number of Outputs Output Voltage Total Output Power (W) Auxiliary Output Voltage Auxiliary Output Power Typical Efficiency
Model: MHV283R3S Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 1 Output Voltage: 3.3 Total Output Power (W): 10 Auxiliary Output Voltage: NA Auxiliary Output Power: NA Typical Efficiency: 72
Model: MHV2805S Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 1 Output Voltage: 5 Total Output Power (W): 15 Auxiliary Output Voltage: NA Auxiliary Output Power: NA Typical Efficiency: 77
Model: MHV2812S Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 1 Output Voltage: 12 Total Output Power (W): 15 Auxiliary Output Voltage: NA Auxiliary Output Power: NA Typical Efficiency: 81
Model: MHV2815S Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 1 Output Voltage: 15 Total Output Power (W): 15 Auxiliary Output Voltage: NA Auxiliary Output Power: NA Typical Efficiency: 81
Model: MHV2805D Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 2 Output Voltage: 5 Total Output Power (W): 15 Auxiliary Output Voltage: -5 Auxiliary Output Power: 7.5 Typical Efficiency: 79
Model: MHV2812D Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 2 Output Voltage: 12 Total Output Power (W): 15 Auxiliary Output Voltage: -12 Auxiliary Output Power: 7.5 Typical Efficiency: 83
Model: MHV2815D Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 2 Output Voltage: 15 Total Output Power (W): 15 Auxiliary Output Voltage: -15 Auxiliary Output Power: 7.5 Typical Efficiency: 83
Model: MHV28512T Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 3 Output Voltage: 5 Total Output Power (W): 15 Auxiliary Output Voltage: +/-1212 Auxiliary Output Power: 5 Typical Efficiency: 78
Model: MHV28515T Nominal Input Voltage: 28 Input Voltage Range: 16-50 Number of Outputs: 3 Output Voltage: 5 Total Output Power (W): 15 Auxiliary Output Voltage: 15 Auxiliary Output Power: 5 Typical Efficiency: 78
