MGA Series™ – 16 to 40 Volt Input – 5 Watts
DC-DC Converters
A surface mountable package with outputs of 5, 12, 15, ±5, ±12 and ±15 volts meet a variety of system needs. The converters are offered with standard screening, “ES” screening, or fully compliant to “883” MIL-PRF-38534 Class H screening. Standard microcircuit drawings (SMD) are available.
Surface mount package, 1.23 in2 (7.9 cm2)
- Operating temperature -55° to +125°C
- Input voltage range 16 to 40 VDC
- Transient protection 50 V for 50 ms
- Fully isolated
- Fixed high frequency switching
- Inhibit function
- Indefinite short circuit protection
- Up to 74% efficiency
- Case size: MGA 1.110 × 1.110 × 0.250 inches (28.19 × 28.19 × 6.35 mm)
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs |
|---|---|---|---|
| Model: MGA2805D | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 2 |
| Model: MGA2805S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
| Model: MGA2812D | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 2 |
| Model: MGA2812S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
| Model: MGA2815D | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 2 |
| Model: MGA2815S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
