MFL Series™ – 16 to 40 Volt Input – 65 Watts
DC-DC Converters
Interpoint® MFL Series is available with a Class H SMD number. They are 28-volt DC-DC converters rated up to 65 watts of output power. The converters are offered with standard screening, “ES” screening, or fully compliant to “883” MIL-PRF-38534 Class H screening. Standard microcircuit drawings (SMD) are available.
Parallel operation with current share, up to 3 units
- Operating temperature -55° to +125°C
- Compliant up to Class H, see datasheet for SMD numbers
- Input voltage range 16 to 40 VDC
- Transient protection 80 V for 50 ms
- Fully Isolated, magnetic feedback
- Fixed high frequency switching
- Remote sense or output trim on single output models
- Inhibit function
- Synchronization input and output
- Indefinite short circuit protection
- Up to 87% efficiency
- Case size: 3.005 × 1.505 × 0.400 inches (76.33x x 38.23 × 10.16 mm)
| Model | Nominal Input Voltage | Input Voltage Range | Number of Outputs |
|---|---|---|---|
| Model: MFL2805D | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 2 |
| Model: MFL2805S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
| Model: MFL2812D | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 2 |
| Model: MFL2812S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
| Model: MFL2815D | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 2 |
| Model: MFL2815S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
| Model: MFL2828S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
| Model: MFL283R3S | Nominal Input Voltage: 28 | Input Voltage Range: 16 to 40 | Number of Outputs: 1 |
