Electrical Power Solutions: Interpoint® FMSA and FMGA™
Electrical Power Solutions: Interpoint® FMSA and FMGA™
Product Type: EMI Filters
Application: High Reliability
Application: High Reliability
FEATURES
- Attenuation
- 50 dB (FMSA-461) at 500 kHz
- 55 dB (FMGA-461) at 500 kHz
- Small footprint
- FMSA-461 0.79 in2 (5.1 cm2)
- FMGA-461 0.89 in2 (5.7 cm2)
- Operating temperature -55° to +125°C
- Nominal 28 volts input, 0 to 50 volts operation
- Up to 0.8 amps throughput current
- Compliant to MIL-STD-461C CE-03
- Compatible with MIL-STD-704 A-E 28 volt power bus
| Model | Nominal Input Voltage | Input Voltage Range |
|---|---|---|
| Model: FMSA28-461 | Nominal Input Voltage: 28 | Input Voltage Range: 0-50 |
| Model: FMGA28-461 | Nominal Input Voltage: 28 | Input Voltage Range: 0-50 |
