FME270 Series™ – 0 to 400 Volts In – 1.5 Amps

Product Type: EMI Filters
Application: High Reliability

The FME270 Series EMI filters reduce the reflected input ripple current of high frequency Interpoint DC-DC converters. One filter can be used with multiple converters up to the rated output current of the filter. The filters are available with standard screening, “ES” screening, or fully compliant to “883” MIL-PRF-38534 Class H screening. DLA drawings are available.

Input voltage 270 VDC
Attenuation 50 dB at 500 kHz, typical
  • Operating temperature -55° to +125°C
  • Nominal 270 V input, 0 V to 400 V operation
  • Up to 1.5 A throughput current
  • Compliant to MIL-STD-461C CE-03
  • Compatible with the MHP270™ Series of converters
  • Case size: 3.005 × 1.505 × 0.400 inches (76.33 × 38.23 × 10.16 mm) – standard case, flanged with short leads, shown in photo
    • Case Options
      • Flanged: leads bent down
      • Tabbed: short leads, leads bent up, and leads bent down
Model Input Voltage Total Output Power (W)/Current (A)
Model: FME270 EMI Filter Input Voltage: 400 Total Output Power (W)/Current (A): 1.5
