Product Type: EMI Filters
Application: High Reliability

The FMCE-0528 EMI  filters reduce the reflected input ripple current of high frequency MOR, MFL, MFX, MWR, MTR, MFK, MHV and MHF+ Series Interpoint® DC-DC converters the bringing them into compliance with Military Standard 461C CE03/CS01 and 461D, E and F CE102/CS101 levels of conducted emissions of converters. One filter can be used with multiple converters up to the rated output current of the filter.

Attenuation to 60 dB at 500 kHz

• Operating temperature -55° to +125°C
• Nominal 28 V input
• -0.5 to 50 V operation without transorb, FMCE-0528
• -0.5 to 40 V operation with transorb, FMCE-0528-TR
• Transient rating -0.5 to 80 V for 1 second
• Up to 5 A throughput current -0.5 to 50 Vin
• Compliant to
— MIL-STD-461C CE03
— MIL-STD-461D, E and F CE102
— MIL-STD-461C CS01
— MIL-STD-461D, E and F CS101
• Compatible with MIL-STD-704 A-E 28 VDC power bus

Model Input Voltage Total Output Power (W)/Current (A)
Model: FMCE-0528 Input Voltage: 50 Total Output Power (W)/Current (A): 5
Model: FMCE-0528-TR Input Voltage: 40 Total Output Power (W)/Current (A): 5
