Product Type: EMI Filters
Application: High Reliability

The FMCE–0328 EMI  filters reduce the reflected input ripple current of high frequency MFX, MWR, MTR, MFK, MHV and MHF+ Series Interpoint® DC-DC converters bringing them into compliance with MIL-STD-461C CE03/CS01 and 461D, E and F CE102/CS101 levels of conducted emissions of converters. One filter can be used with multiple converters up to the rated output current of the filter.

Attenuation to 60 dB at 500 kHz

• Operating temperature -55° to +125°C
• Nominal 28 V input, -0.5 to 50 V operation
• Transient rating -0.5 to 80 V for 1 second
• Up to 3 A throughput current -0.5 to 50 Vin
• Compliant to
— MIL-STD-461C CE03
— MIL-STD-461D, E and F CE102
— MIL-STD-461C CS01
— MIL-STD-461D, E and F CS101
• Compatible with MIL-STD-704 A-E 28 volt power bus

Model Nominal Input Voltage Total Output Power (W)/Current (A)
Model: FMCE-0328 Nominal Input Voltage: 28 Total Output Power (W)/Current (A): 3
